Description:

Color corrected infinity optical system (CSIS), excellent optical performance and great image.
Application of high-contrast and low chromatic phase contrast observation, access to detailed examination of internal structure of the cells.
Supply long working distance and high N.A. objectives to get flat and clear image.
Long working distance condenser has capacity to use revolution bottle and suit for various sample containers.
Well-designed body structure, durable, high resistance of vibration.
Low position coaxial coarse and fine adjustment, ergonomic design.

Specification:

Optical System	Infinity Color Corrected Optical System
Head	Binocular Head
	Gemel Viewing Head, 45 Degree Inclined, Interpupilary Distance 54-75mm, Spliting Ratio 80:20
Eyepiece	PL10x/22mm, High Eyepoint, Wide Field
Nosepiece	Revolving Quintuple Nosepiece
Objective	Long Working Distance Infinity Plan Achromatic Objectives


	LWD Infinity Plan Phase Contrast Objectives
Stage	Fixed Stage Size 250*160mm, Slider Clips --Glass Plate --Metal Plate --Petri Dish Holder, Dia.35mm
Focusing	Coaxial Coarse & Fine Focusing System, Coarse Adjustment Range 9mm, Fine Adjustment Precision 0.002mm,with Tension Adjustment, with Safty Stop
Condenser	N.A.0.3 Kohler Illumination Condenser, with Phase Adjustable Slide Plate, Long Working Distance 72mm. The Whole Set Can Be Rotated Down
Phase Contrast	Phase Contrast Plug-board for 10x-40x, Center Adjustable Centering Telescope Dia. 30mm
Filter	Dia.45mm Green Interference Filter Dia.45mm Color Temperature Change Filter
Light	Critical Illumination, With Iris Aperture, Halogen 6V30W, Pre-centered, Intensity Adjustable
Power	Wide Voltage 90-240V
